Inspection Machine

Inspection Machine

Ensure flawless material quality and accurate printing with our Inspection Machine, designed to detect defects, wrinkles, or printing errors in paper, film, and laminated rolls. The machine offers high-precision scanning, smooth operation, and consistent performance for quality assurance across production lines. Its intelligent design includes user-friendly controls, adjustable tension systems, and efficient defect reporting, allowing operators to maintain continuous production without compromising on quality. Suitable for printing, packaging, and converting industries, this machine helps manufacturers achieve superior product standards, reduce waste, and maintain high efficiency throughout the inspection process.

Technical Specifications

Machine Name MOHINDRA High Speed Inspection Machine
Mechanical Speed 450 Mtr./min (Depends on type, roll condition, tension range, operator skill)
Unwinder Unwind Stands, Shaft Less
Maximum Roll Diameter 1000 mm
Inside Cone Diameter 76/152 mm
Direction Unwinding Two (2) Direction Unwinding
Rewinder-1 Maximum Roll Diameter 1000 mm
Inside Core Diameter 152 mm
Direction Rewinding Two (2) Direction Rewinding
Direction Rewinding (Secondary) One (1) Direction Rewinding
Web Guiding Ultrasonic edge guiding with A.C. motor actuator at both unwinder and rewinder
Lighting Full width strobe light and a light box
Pasting Table Arrangement to strip off defected material and paste new web; Separate Rewinder-2 for rejected laminates
Drive Motors AC Vector grade Motor with Digital AC Vector drives (Unwinder, Main Motor, Rewinder-1, Rewinder-2)
Motor Type 1 AC Asynchronous motor, 1 AC induction motor, 1 AC Asynchronous motor, 1 AC Induction Motor
Hand of Line Customer's choice
Electric Supply Voltage 415 VAC ±10%, 50 Hz ±1%, 3 Phase
Features
  • 1. High speed inspection for various materials
  • 2. Two-direction unwinding and rewinding for flexibility
  • 3. Ultrasonic edge guiding system for precise alignment
  • 4. Full width strobe light and light box for defect detection
  • 5. Pasting table for correcting defective material
  • 6. AC vector drive motors for smooth operation
  • 7. Multiple motor types for different drive applications
  • 8. Customizable hand of line according to customer requirements
  • 9. Suitable electric supply range: 415 VAC ±10%, 50 Hz ±1%, 3 Phase
